Items
|
Specification
|
Remarks
|
|
Product Weight
|
1KG
|
|
|
Size
|
Customized
|
|
|
Capactiy
|
5.2AH
|
1C discharge
|
|
Platform Voltage
|
36V
|
|
|
Discharge cut-off voltage
|
29V
|
|
|
Charge cut-off voltage
|
42V
|
|
|
Standard Charging
|
<=5A
|
|
|
Standard Discharging
|
10A
|
|
|
Discharging current(MAX)
|
30A
|
|
|
Short circuit protection
|
YES
|
|
|
Short-circuit protection recovery
|
Disconnect the load
|
|
|
Cycel Life
|
500th cycle>90% of 1st Cycle Capacity or 1000th cycle>80% of 1st Cycle Capacity,
|
25℃,Standard charging; Discharge:1C to 29V
|
|
Discharge Characteristics (by temperature)
|
55℃ ≥100%
25℃ =100% 10℃ ≥90% 0℃ ≥80% -10℃ ≥75% -20℃ ≥70 |
Discharge: CC 1C to 29V cut-off at each temperature(-20℃ 2.2V cut-off)
|
|
Storage Characteristics
|
Recoverable capacity≥85%
|
100%SOC, discharge 30min at 2C current then storage 28 days at 45℃, recoverable capacity will be tested at 25℃±2℃
|
|
Use Temperature
|
Charge：0 to 45℃
Discharge：-20 to 60℃ |
|
