Motor Features
*The motor is suitable for agricultural drones, rescue drones, survey drones and a series of civil drones. *The motors can also be applied to a series of machines such as robots, smart homes, automation equipment, etc. according to the actual use. *The motor belongs to the external rotation motor, that is, the outside of the housing part of the rotation. *By default the motor does not contain sensors, such as Hall sensors and temperature sensors, if you need to add please contact customer service. *For the motor accessories ESC and propeller we can provide, if you need, please contact customer service.
|
Parameters
|
|
|
Motor Model
|
QM9025
|
|
KV Value
|
90KV
|
|
Structure
|
36N42P
|
|
Stator diameter
|
82mm
|
|
Stator length
|
25mm
|
|
Size
|
Ф91*51mm
|
|
Weight
|
900g
|
|
No-load current
|
2.5A
|
|
Voltage
|
8S/14S
|
|
Max power(10s)
|
4000W
|
|
Max current(10s)
|
75A
|
Attention!!!
The above parameters are tested for specific motors at specific voltages and specific KV values, and the data are for reference only. The final data will vary according to the actual voltage and KV in use, and you can consult customer service for professional advice on the specific data. Also, you can send your data requirements to customer service and engineers for professional advice and customization.
-->
